Multi-Slide Plus Window
Multi-slide panels glide smoothly out of sight, with pocketing, stacking, directional, and 90º corner configurations for maximum flexibility.
Multi-Slide Plus Window
Multi-Slide Plus windows stack, pocket, or wrap 90-degree corners to open rooms to the outdoors. Matching doors feature a rated drop-in sill for higher performance and easy installation.
1″ (25.4 mm) sill height with interior sill stop height options of 1-1/8″ (28.6 mm), 1-3/4″ (44.5 mm), or 2-1/8″ (54.0 mm).
Optional T-tracks available in 11/16″ (17.5 mm), 1-1/8″ (28.6 mm), and 1-5/8″ (41.3 mm) heights in place of draining sill (no rating).
Max panel width 60″ (1524 mm), max height 120″ (3048 mm).
2-1/4″ (57.2 mm) panel thickness.
Single direction, up to 5-panels. Multi-direction up to 10-panels.
Panels are clad in .075″ (1.91 mm) extra heavy-duty extruded aluminum.
Two 2-1/8″ (54.0 mm) machined Delrin wheels with sealed stainless steel precision bearings and stainless steel carriage carry each panel for a smooth-as-silk glide.
Head track and side jambs with thermal break are dark bronze anodized.
Largest selection of options including 70 exterior colors in the industry’s very best AAMA 2605 powder-coating for the longest-lasting color.
Multi-Slide Plus Window
Multi-Slide Plus windows stack, pocket, or wrap 90-degree corners to open rooms to the outdoors. Matching doors feature a rated drop-in sill for higher performance and easy installation.
1″ (25.4 mm) sill height with interior sill stop height options of 1-1/8″ (28.6 mm), 1-3/4″ (44.5 mm), or 2-1/8″ (54.0 mm).
Optional T-tracks available in 11/16″ (17.5 mm), 1-1/8″ (28.6 mm), and 1-5/8″ (41.3 mm) heights in place of draining sill (no rating).
Max panel width 60″ (1524 mm), max height 120″ (3048 mm).
2-1/4″ (57.2 mm) panel thickness.
Single direction, up to 5-panels. Multi-direction up to 10-panels.
Panels are clad in .075″ (1.91 mm) extra heavy-duty extruded aluminum.
Two 2-1/8″ (54.0 mm) machined Delrin wheels with sealed stainless steel precision bearings and stainless steel carriage carry each panel for a smooth-as-silk glide.
Head track and side jambs with thermal break are dark bronze anodized.
Largest selection of options including 70 exterior colors in the industry’s very best AAMA 2605 powder-coating for the longest-lasting color.
*Note: Due to the low profile of the T-Tracks and 1-1/8″ (28.6 mm) interior sill stop, there is no water infiltration performance rating on this sill stop height. Application requires consideration of potential exposure to weather events and elevation/location of the door system.
