Sierra Pacific Lift & Slide Door Systems are a builder favorite for their smooth operation and smart engineering. A premium roller system lifts panels to glide effortlessly, then lowers them to lock securely—delivering superior energy efficiency, weather resistance, and security. Perfect for large openings that maximize space and performance.
Unencumbered views up to 10’ (3,048 mm) high and 23’ (7,010 mm) wide
Stacking or pocketing in single and bi-parting operations
Single direction: up to 5 panels
Multi-directional: up to 10 panels
4-5/8” (117 mm) stile widths
4-5/8” (117 mm) or 6-3/8” (162 mm) head rail heights
6-3/8” (162 mm), 10-1/4” (260 mm), or 12” (305 mm) bottom rail heights
2-1/4” (57 mm) thick panels
Max panel height: 120” (3,048 mm), max panel width: 72” (1,829 mm)
Protected by our exclusive CoreGuard Plus™, the industry’s best wood protection
Constructed of the heaviest extruded aluminum cladding: .062” (1.6 mm) thick frame & .075” (1.9 mm) thick panels
Innovative door sill with low-profile drain track made of thermally broken extruded aluminum in dark bronze anodized finish; standard height 1” (25 mm). Intruding water drains through exterior weep gates or via installed drain tubes
Continuous extruded nailing flange as part of the frame extrusion for superior installation
Largest selection of options, including 50 exterior finishes in the industry’s best AAMA 2605 powder-coating for long-lasting color
